Pneumatic Cylinder

Pneumatic Cylinder

– High-Performance Linear Actuator for Industrial Automation

     The  Pneumatic Cylinder, a reliable linear actuator designed to convert compressed air into controlled mechanical motion. Engineered for smooth operation, high repeatability, and long service life, this cylinder is ideal for a wide range of industrial applications requiring fast and accurate movement.

Built with precision-machined components and high-quality sealing systems, our pneumatic cylinders deliver consistent force output, minimal friction, and excellent durability even under continuous operation. The compact and robust design ensures easy integration into automation equipment, making it a preferred choice for modern manufacturing and motion control systems.

Key Features

• Smooth Linear Motion: Converts compressed air into precise and stable movement
• High Repeatability: Ensures consistent positioning accuracy in automation processes
• Durable Construction: مقاوم to wear, pressure, and long-term operation
• Low Friction Performance: Optimized internal design for efficient operation
• Leak-Resistant Sealing System: Enhances reliability and reduces maintenance
• Flexible Mounting Options: Compatible with various industrial setups
• Custom Stroke & Bore Sizes

Applications

• Industrial automation and robotics
• Assembly lines and manufacturing systems
• Packaging and material handling equipment
• CNC machinery and tooling systems
• Food processing and pharmaceutical equipment
• Automotive production lines

Manufacturing Process

• CNC Precision Machining (cylinder barrel, end caps, piston components)
• Honing Process (for internal cylinder bore to ensure smooth surface finish)
• Precision Grinding (for piston rods and sealing surfaces)
• Surface Treatment (anodizing, chrome plating, or passivation)
• Seal Assembly (high-performance O-rings and sealing elements)
• Pressure Testing & Leak Inspection

Tolerance & Dimensions

• Bore Diameter Tolerance: H8 / ±0.01–0.02 mm
• Piston Rod Tolerance: h6 / high precision fit
• Stroke Length Tolerance: ±0.1 mm (customizable)
• Surface Roughness (Bore): Ra 0.4–0.8 μm
• Working Pressure Range: Typically 0.1–1.0 MPa (customizable)

OEM / ODM Manufacturing Capability

As a professional OEM/ODM manufacturer, we specialize in high-precision pneumatic components and automation solutions. With advanced machining, honing, and assembly capabilities, we provide customized pneumatic cylinders tailored to your performance and application requirements.

• Custom bore sizes, stroke lengths, and mounting types
• Material selection based on environment and load conditions
• Seal customization for temperature and media compatibility
• Branding, logo marking, and packaging services
• Rapid prototyping and scalable production

If you are sourcing a “Pneumatic Cylinder”, air cylinder actuator, industrial pneumatic actuator, linear air cylinder, CNC machined pneumatic cylinder, automation cylinder, double acting cylinder OEMwe offer reliable, precision-engineered solutions tailored to your market. Contact us now for OEM customization, samples, or bulk quotations.
