Cylinder Flange Mounting Plate

Cylinder Flange Mounting Plate

– Heavy-Duty Base for Pneumatic & Hydraulic Cylinder Installation

      The Cylinder Flange Mounting Plate, specifically engineered to provide a rigid and reliable mounting base for pneumatic and hydraulic cylinders. Designed for vertical or face mounting applications, this component allows precise alignment and firm fixation of cylinders onto flat machine surfaces, improving operational stability and load distribution.

Manufactured from high-strength metals such as carbon steel or cast aluminum, this flange plate delivers excellent durability, structural integrity, and resistance to mechanical stress. Its optimized design features a central bore for cylinder rod or body clearance, along with multiple precision-machined bolt holes for easy and secure installation.

Ideal for industrial machinery and automation systems, this mounting plate ensures consistent performance, reduced vibration, and extended service life of connected components.

Key Features

• Stable Mounting Support: Provides a solid base for vertical or face-mounted cylinders
• High Load Capacity: Designed to withstand heavy-duty industrial applications
• Precision Bolt Hole Layout: Ensures accurate alignment and secure installation
• Robust Metal Construction: مقاوم to wear, pressure, and deformation
• Versatile Compatibility: Suitable for both pneumatic and hydraulic cylinders
• Easy Installation & Maintenance

Applications

• Pneumatic cylinder mounting systems
• Hydraulic cylinder installations
• Industrial automation and machinery
• Manufacturing and assembly equipment
• Construction and heavy-duty mechanical systems

Manufacturing Process

• CNC Machining (milling, drilling, and contour shaping)
• Casting or Forging (for base structure depending on material)
• Precision Boring (for central hole and alignment features)
• Thread Tapping (for mounting holes if required)
• Surface Finishing (deburring, grinding)
• Surface Treatment (zinc plating, powder coating, anodizing)
• Final Inspection (dimensional accuracy and load testing)

Tolerance & Dimensions

• Center Bore Tolerance: H7 / ±0.01–0.02 mm
• Bolt Hole Position Tolerance: ±0.02–0.05 mm
• Flatness & Parallelism: High precision for stable mounting
• Thickness Tolerance: ±0.05 mm
• Load Capacity: Customizable based on material and design

OEM / ODM Manufacturing Capability

As a professional OEM/ODM manufacturer, we specialize in high-precision mechanical and structural components for industrial applications. With advanced machining, casting, and finishing capabilities, we deliver customized mounting solutions tailored to your exact specifications.

• Custom dimensions, hole patterns, and thickness
• Material selection based on load and environmental requirements
• Surface treatment options for corrosion resistance
• Logo marking and private labeling
• Rapid prototyping and scalable production

If you are sourcing a “Cylinder Flange Mounting Plate”, pneumatic cylinder mount plate, hydraulic cylinder flange, CNC machined mounting plate, industrial cylinder base plate, steel flange mount, automation mounting bracket OEMwe offer reliable, precision-engineered solutions tailored to your market. Contact us now for OEM customization, samples, or bulk quotations.
